Designed and engineered at our world-famous Acoustic Engineering Center of Excellence in Northridge, California, the Stage 220P is 500W and is the most powerful subwoofer in the Stage Series and delivers the low frequency excitement that customers crave. This subwoofer features a high excursion 12-inch (300mm) Poly cellulose low-frequency woofer with dual rear firing tuned ports that provides deep, powerful, signature JBL bass. A full complement of controls provides for easy system integration.
Specification:
- Type: Powered Subwoofer
- Low Frequency Driver: 12-inch (300mm) Poly cellulose Ribbed High Excursion
- Amplifier Power: 250W RMS (500W Dynamic)
- Frequency Response ± 6dB: 26Hz-150Hz
- Crossover Frequencies: 50Hz-150Hz (variable) 24dB/octave
- Controls: 35Hz-150Hz
- Controls: Auto Power, Crossover, Level, Phase
- Inputs: One (1) Line-Level LFE Input
- Enclosure Tuning: Bass-Reflex via Dual Rear-Firing Tuned Ports
- Power Requirements: 120V, 60Hz (US) 220-230V, 50/60Hz (EU)
- Power Consumption: <0.5W (standby) / 205W/1.6A (max – 230V) / 205W/3.15A (max – 120V)
- Finish: Espresso or Latte
- Dimensions (HxWxD): 16.4in x 15.9in x 17.5in (416mm x 405mm x 444mm)
- Product Weight: 41.2 lbs. (18.7 kg)
Features:
- 12-inch (300mm) Polycellulose Ribbed Cone Low-Frequency Woofer
- 250W RMS (500W Dynamic)
- Dual Rear-Firing Tuned Ports
- Crossover, Level and Phase Control
What's in the box?
- 1 x 220P
- 1 x Power Cord
- 4 x Floor Spikes
- 1 x Speaker Grille
- 1 x Safety Sheet
- 1 x Quick-Start Guide
